High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable

    Buy cheap High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable from wholesalers

    Buy cheap High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable from wholesalers
    • Buy cheap High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable from wholesalers
    • Buy cheap High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable from wholesalers
    • Buy cheap High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable from wholesalers

    High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable

    Ask Lasest Price
    Brand Name : China chao sheng
    Model Number : CSPCB1529
    Certification : ISO/UL/RoHS/TS
    Price : usd1.68/pcs
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000K/pcs per month
    Delivery Time : 15-20day
    • Product Details
    • Company Profile

    High Power Module PCB Circuit Board Prototyping Service 8 Layers 3 Steps Durable

    8 layers 3 steps + embedded copper optical module ManufacturerPCB , RT6010+Panasonic M6Opticalmodule product Flexib le Rigid PCB rigid flex board Anylayer, minimum line width 3/3mil, minimum hole 0.10mm, mechanical

    Printed circuit board (pcb) and PCBA products
    Communication terminal, communication station, electronic communication, optical fiber, optical module, communication equipment, communication instrument, computer, household appliance, testing equipment, testing instrument, instrument, SD card, SG card, mobile phone, computer, various antennas, cars, music Equipment, playback equipment, banking equipment, medical instruments, medical equipment, medical equipment, aerospace, aviation, military, LED, OLED, OLCD power control power supply, industrial power supply, communication power supply, automotive power supply, office equipment, digital products,computers,etc.Applications;
    Flexible circuit board (FPC) and FPCA product areas
    CD, hard disk, printer, fax machine, scanner, sensor, mobile phone, connector, module, walkie-talkie antenna card, high-end camera, digital camera, laser head, CD, medical, instrumentation, drive, automotive instrumentation, medical instrument, Medical equipment, banking equipment, industrial instruments, LED light bars, military, aviation, aerospace, defense and other high-tech products, of which more than 70% of the products are exported to Europe, America, Europe, Central Europe, Western Europe, Southeast Asia, Asia-Pacific and other countries and area.

    blind hole, electric gold + immersion gold, green oil, white
    Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB
    Standard.
    Quantities range from prototype to volume production.
    100% E-Test
    PCB, FPC process production capability

    PCBs material: FR-4, 0.5oz - 6oz copper
    0.45 to 3.2mm thickness
    Minimum line width and line spacing: 4mil/4mil
    Minimum hole diameter: 0.2mm
    Maximum panel size: 680 x 1280mm
    Surface finishing:
    • HAL, alpha level, gold plating, ENTech
    • HAL or tin and gold plating
    Solder mask type: liquid photoimageable solder mark
    Precision V-cut or routing for panel form design
    OEM orders for SMT and A/I assembly projects accepted
    Gerber file preferred
    Please note the following information are for your reference on our manufacturing capability, not for inquiries on quotations
    We will offer our best prices if you can send your own PCB design


    Product Details:
    Place of Origin:China
    Brand Name:XCE
    Certification:CE,ROHS, FCC,ISO9008,SGS,UL
    Model Number:XCEH
    Minimum Order Quantity:1pcs
    Price:negotiation
    Packaging Details:inner: vacuum-packed bubble bag outer: carton box
    Delivery Time:5-10 days
    Payment Terms:T/T,Western union
    Supply Ability:1, 000, 000 PCS / week

    Advantage Highlights

    • Specialized in 2- to 32-layer PCB
    • ISO 9001-, ISO 14001- and ISO/TS 16949-certified
    • Products are UL- and RoHS-certified
    • Partner for over 2000 small- and medium-scale customers
    • Two factory bases totaling 22,000 square meters
    • Less than 12-hours quick response to inquiries
    • Widely acclaimed and satisfying services
    • Over 66% of PCBs are exported to international markets

    Parameter:

    oItemData
    1Layer:1 to 24 layers
    2Material type:FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers
    3Board thickness:0.20mm to 3.4mm
    4Copper thickness:0.5 OZ to 4 OZ
    5Copper thickness in hole:>25.0 um (>1mil)
    6Max. Board Size:(580mm×1200mm)
    7Min. Drilled Hole Size:4mil(0.1mm)
    8Min. Line Width:3mil (0.075mm)
    9Min. Line Spacing:3mil (0.075mm)
    10Surface finishing:HASL / HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating
    11Solder Mask Color:Green/Yellow/Black/White/Red/Blue
    12Shape tolerance:±0.13
    13Hole tolerance:PTH: ±0.076 NPTH: ±0.05
    14Package:Inner packing: Vacuum packing / Plastic bag,Outer packing: Standard carton packing
    15Certificate:UL,SGS,ISO 9001:2008
    16Special requirements:Buried and blind vias+controlled impedance +BGA
    17Profiling:Punching, Routing, V-CUT, Beveling


    Place of Origin:

    Guangdong China (Mainland)

    Brand Name:

    XCE

    Model Number:

    XCEPCB008

    Base Material:

    FR4

    Copper Thickness:

    0.3-3oz

    Board Thickness:

    0.3-6mm

    Min. Hole Size:

    0.2mm

    Min. Line Width:

    3mil

    Min. Line Spacing:

    3mil

    Surface Finishing:

    HASL, OSP, Immersion Gold/Au, Immersion silver, etc.

    Solder mask:
    Green
    PCB Standard:

    IPC-A-610 E Class II-III

    Wrap and twist:

    5%

    Layer Count:

    1-22

    profiling punching:

    Routing, V-CUT, Beveling

    Max board size:

    1200mm*600mm

    Hole tolerance:

    PTH:±0.075,NTPH:±0.05

    PCB Tolerance of finished thickness:

    ±5%

    PCB:

    Customized

    Product name:

    pcb


    Benefits:
    High dielectric constant for circuit size reduction
    Low loss. Ideal for operating at X-band or below
    Tight εr and thickness control for repeatable circuit performance
    Typical Applications:
    Space Saving Circuitry
    Patch Antennas
    Satellite Communications Systems
    Power Amplifiers
    Aircraft Collision Avoidance Systems
    Ground Radar Warning Systems
    Competitive Advantage:
    1) With UL,ROHS,ISO,IPC
    2).Lead time:3-10 working days
    3)Competitive price best quality
    4)Rich 20 years experience in High Tg Multilayer PCB


    ItemsManufacturing CapabilitiesRemarks
    Number of Layers1-10 layersFor orders above 10 layers,please view the below “Standard PCB” or contact our sales rep.
    MaterialFR-4,AluminumFor Flex, Rigid-flex, Metal-based (Aluminum etc.,), HDI, Halogen-free, High Tg, etc.,please view the below “Standard PCB” or contact sales rep.
    Maximum PCB Size(Dimension)500*1100mm (min 5*6mm)Any sizes beyond this dimension, please view the below “Standard PCB” or contact sales rep.
    Board Size Tolerance(Outline)±0.2mm/±0.5mm±0.2mm for CNC routing, and ±0.5mm for V-scoring.
    Board Thickness0.2-2.4mm0.2,0.4, 0.6, 0.8, 1.0, 1.2, 1.6, 2.0, 2.4mm. Please view the below “Standard PCB” or contact us if your board exceeds these.
    Board Thickness Tolerance(t≥1.0mm)±10%Normally “+ Tolerance” will occur due to PCB processing steps such as electroless copper, solder mask and other types of finish on the surface.
    Board Thickness Tolerance(t<1.0mm)±0.1mm
    Min Trace0.1mm/4milMin manufacturable trace is 4mil(0.1mm), strongly suggest to design trace above 6mil(0.15mm) to save cost.
    Min SpacingMin manufacturable spacing is 4mil(0.1mm), strongly suggest to design spacing above 6mil(0.15mm) to save cost.
    Outer Layer Copper Thickness1oz/2oz/3oz(35μm/70μm/105μm)Also known as copper weight. 35μm=1oz, 70μm=2oz, 105μm=3oz. Please view the below “Standard PCB” or contact us if you need copper weight greater than 3oz.
    Inner Layer Copper Thickness1oz/1.5oz(35μm/50μm)Inner copper weight as per customer’s request for 4 and 6 layers. Please contact us if you need copper weight greater than 1.5oz.
    Drill Sizes (CNC)0.2-6.3mmMin drill size is 0.2mm, max drill is 6.3mm. Any holes greater than 6.3mm or smaller than 0.3mm will be subject to extra charges.
    Min Width of Annular Ring0.15mm(6mil)For pads with vias in the middle, Min width for Annular Ring is 0.15mm(6mil).
    Finished Hole Diameter (CNC)0.2mm-6.2mmThe finished hole diameter will be smaller than size of drill bits because of copper plating in the hole barrels
    Finished Hole Size Tolerance(CNC)±0.08mmFor example, if the drill size is 0.6mm, the finished hole diameter ranges from 0.52mm to 0.68mm will be considered acceptable.
    Solder MaskLPILiquid Photo-Imageable is the mostly adopted. Thermosetting Ink is used in the inexpensive paper-based boards.
    Minimum Character Width(Legend)0.15mmCharacters of less than 0.15mm wide will be too narrow to be identifiable.
    Minimum Character Height (Legend)0.8mmCharacters of less than 0.8mm high will be too small to be recognizable.
    Character Width to Height Ratio (Legend)1:5In PCB silkscreen legends processing, 1:5 is the most suitable ratio
    Minimum Diameter of Plated Half Holes0.6mmDesign Half-Holes greater than 0.6mm to ensure better connection between boards.
    Surface FinishingHASL with lead
    HASL lead free
    Immersion gold,OSP
    The most popular three types of PCB surface finish. Please view the below “Standard PCB” or contact us for other finishes.
    Solder MaskGreen ,Red, Yellow, Blue, White ,BlackNo extra charge (Green, Red, Yellow, Blue)
    SilkscreenWhite, Black, NoneNo extra charge.
    PanelizationV-scoring,
    Tab-routing,
    Tab-routing with Perforation (Stamp Holes)
    Leave min clearance of 1.6mm between boards for break-routing. For V-score panelization, set the space between boards to be zero.
    OthersFly Probe Testing (Free) and A.O.I. testing(free), ISO 9001:2008 ,UL CertificateNo extra charge.
    ItemsSampleHigh Volume
    Single Sided PCB1-34-7
    Double Sided PCB2-57-10
    Multi-layer PCB7-810-15
    PCB Making & Assembly8-1515-20
