    ​0.80MM Thickness Printed Circuit Board Assembly Services FR-4 TG140 Material 10 Layers

    Ask Lasest Price
    Brand Name : China chao sheng
    Model Number : CSPCB1514
    Certification : ISO/UL/RoHS/TS
    Price : USD1.0/pcs
    Payment Terms : T/T, Western Union
    Supply Ability : 500000pcs per month
    Delivery Time : 15-18day
    • Product Details
    • Company Profile

    ​0.80MM Thickness Printed Circuit Board Assembly Services FR-4 TG140 Material 10 Layers

    10 layers ​ FR-4, TG140 Seeed Fusion PCB Specification Panelization and Bridge Design

    Component Layout Considerations PCB Hole design Solder Mask Design Copper Trace Design

    PCB Lamination Structure

    1. Printed circuit board (pcb) and PCBA products
      Communication terminal, communication station, electronic communication, optical fiber, optical module, communication equipment, communication instrument, computer, household appliance, testing equipment, testing instrument, instrument, SD card, SG card, mobile phone, computer, various antennas, cars, music Equipment, playback equipment, banking equipment, medical instruments, medical equipment, medical equipment, aerospace, aviation, military, LED, OLED, OLCD power control power supply, industrial power supply, communication power supply, automotive power supply, office equipment, digital products,computers,etc.Applications;
      Flexible circuit board (FPC) and FPCA product areas
      CD, hard disk, printer, fax machine, scanner, sensor, mobile phone, connector, module, walkie-talkie antenna card, high-end camera, digital camera, laser head, CD, medical, instrumentation, drive, automotive instrumentation, medical instrument, Medical equipment, banking equipment, industrial instruments, LED light bars, military, aviation, aerospace, defense and other high-tech products, of which more than 70% of the products are exported to Europe, America, Europe, Central Europe, Western Europe, Southeast Asia, Asia-Pacific and other countries and area.

    Quick Details

    • Surface Finishing: gold plating
    • Min. Line Spacing: 0.11mm
    • Min. Line Width: 0.11mm
    • Min. Hole Size: 0.25mm
    • Board Thickness: 1.0mm
    • Copper Thickness: 1oz
    • Base Material: FR4
    • Model Number: 14
    • Brand Name: XHPCB

    Specifications


    6 layer gold plating PCB multilayer PCB


    Packaging Details:vacuum and carton
    Delivery Detail:5-15workdays

    XHPCB was established in 2006, located in ShenZhen of China,occupy 3000 square meters, there are 200 employees,10 engineers.

    we engaged in all kinds of PCB design, manufacture services over tenyears, we are a ODM and OEM factory,

    Main for Single-Sided Board, Double-Sided Board, Multilayer Board,Blind via Multilayer board, Buried via multilayer board, and so on.

    PCB specification: conductor line/space≧0.01mm, holediameter≧0.2mm, layer quantity≦8

    Surface treatment: HASL(lead free) ,HASL(with lead), immersion gold,immersion silver,gold plated ,OSP and so on.

    Usage: electronic products, Digital product, LED, auto, communication,Medical,home appliance, computers, consumption goods and so on.

    Medical,home appliance, computers, consumption goods and so on.

    1: Medical Bluetooth module motherboard
    2:
    Halogen-free FR-4 TG180, inner and outer copper thickness 35um, minimum line width line spacing 3/3mil, hole ratio 10:1, minimum hole 0.10mm, blind hole buried hole, immersion gold, red solder resist, white
    3: The board thickness is 1.60mm,
    4: blind hole, resin plug hole + plating hole
    Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB
    Standard.
    Quantities range from prototype to volume production.
    100% E-Test

    FAQ:

    Q: What files do you use in PCB fabrication?

    A: Gerber or Eagle, BOM listing, X, Y sitting report, PNP and Components Position

    Q: Is it possible you could offer sample?

    A: Yes, we can custom you sample to test before mass production

    Q: When will I get the quotation after sent Gerber, BOM and test procedure?

    A: Within 6-48hours for PCB quotation and around 24-48 hours for PCBA quotation.

    Q: According to the difficulty of high-layer boards, How can I know the process of my PCB production?

    A: 7-35days for PCB production and components purchasing, and 14-20days for PCB assembly and Testing

    Q: How can I make sure the quality of my PCB?

    A: We ensure that each piece of PCB, PCBA products work well before shipping. We'll test all of them according to your test procedure.

    PCB, FPC process production capability

    1: Medical Bluetooth module motherboard
    2:
    Halogen-free FR-4 TG180, inner and outer copper thickness 35um, minimum line width line spacing 3/3mil, hole ratio 10:1, minimum hole 0.10mm, blind hole buried hole, immersion gold, red solder resist, white
    3: The board thickness is 1.60mm,
    4: blind hole, resin plug hole + plating hole
    Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB
    Standard.
    Quantities range from prototype to volume production.
    100% E-Test

    FAQ:

    Q: What files do you use in PCB fabrication?

    A: Gerber or Eagle, BOM listing, X, Y sitting report, PNP and Components Position

    Q: Is it possible you could offer sample?

    A: Yes, we can custom you sample to test before mass production

    Q: When will I get the quotation after sent Gerber, BOM and test procedure?

    A: Within 6-48hours for PCB quotation and around 24-48 hours for PCBA quotation.

    Q: According to the difficulty of high-layer boards, How can I know the process of my PCB production?

    A: 7-35days for PCB production and components purchasing, and 14-20days for PCB assembly and Testing

    Q: How can I make sure the quality of my PCB?

    A: We ensure that each piece of PCB, PCBA products work well before shipping. We'll test all of them according to your test procedure.

    PCB, FPC process production capability

    Technical ltemMassProductAdvanced Technology
    201620172018
    Max.Layer Count26L36L80L
    Through-hole plate2~45L2~60L2~80L
    Max.PCBSize(in)24*52"25*62"25*78.75"
    The layer number of FPC1~36L1~50L1~60L
    Max.PCBSize(in)9.8"*196"9.8"*196"10"*196"Reel to reel
    Layeredplatelayer2~12L2~18L2~26L
    Max.PCBSize(in)9"*48"9"*52"9"*62"
    Combination of hard and soft layers3~26L3~30L3~50L
    Interconnect HDI5+X+5Interconnect HDI7+X+7Interconnect HDI8+X+8,Interconnect HDI
    HDI PCB4~45L4~60L4~80L
    Interconnect HDI3+20+34+X+4Interconnect HDI4+X+4,Interconnect HDI
    Max.PCBSize(in)24"*43"24"*49"25"*52"
    MaterialFR-4 RogersFR-4 RogersFR-4 Rogers
    Base materialHalogenfree,LowDKHalogenfree,LowDKHalogenfree,LowDK
    Build-up MaterialFR-4FR-4FR-4
    BOard,Thickness(mm)Min.12L(mm)0.430.42~8.0mm0.38~10.0mm
    Min.16L(mm)0.531.60~8.0mm0.45~10.0mm
    Min.18L(mm)0.632.0~8.00.51~10.0mm
    Min.52L(mm)0.82.50~8.0mm0.65~10.0mm
    MAX(mm)3.510.0mm10.0mm
    Min.CoreThickness um(mil)254"(10.0)254"(10.0)0.10~254(10.0mm)
    Min.Build up Dielectric38(1.5)32(1.3)25(1.0)
    BaseCopperWeightInner Layer4/1-8 OZ4/1-15 OZ4/1-0.30mm
    Out Layer4/1-10 OZ4/1-15 OZ4/1-30 OZ
    Gold thick1~40u"1~60u"1~120u"
    Nithick76~127u"76~200u"1~250u"
    Min.HOle/Land um(mil)150/300(6/12)100/200(4/8)100/200(4/8)
    Min.Laser via/landum(mil)60/170(2.4/6.8)50/150(2/6)50/150(2/6)
    Min. IVH,Hole size/landum(mil)150/300(6/12)100/200(4/8)100/200(4/8)
    DieletricThickness38(1.5)32(1.3)32(1.3)
    125(5)125(5)125(5)
    SKipviaYesYesYes
    viaoNhie(laserviaon BuriedPTH)YesYesYes
    Laser Hole FillingYesYesYes
    TechnicalltemMass ProductAdvanced Technolgy
    2017year2018year2019year
    Drill hole depth ratioThroughHole2017year.40:1.40:1
    Aspet RatioMicro Via.35:11.2:11.2:1
    Copper Filling Dimple Size um(Mil)10(0.4)10(0.4)10(0.4)
    Min.LineWidth&spacelnner Layer um(mil)45/45(1.8/1.8)38/38(1.5/1.5)38/38(1.5/1.5)
    Plated Layer um(mil)45/45(1.8/1.8)38/38(1.5/1.5)38/38(1.5/1.5)
    BGAPitch mm(Mil)0.30.30.3
    Min.PTH Hole ring um(mil)75(3mil)62.5(2.5mil)62.5(2.5mil)
    Line Width Control∠2.5MIL±0.50±0.50±0.50
    2.5Mil≤L/W∠4mil±0.50±0.50±0.50
    ≦3mil±0.60±0.60±0.60
    Laminated structureLayer by layer3+N+34+N+45+N+5
    Sequential Build-up20L Any Layer36L Any Layer52L Any Layer
    Multi-layer overlayN+NN+NN+N
    N+X+NN+X+NN+X+N
    sequential Lamination2+(N+X+N)+22+(N+X+N)+22+(N+X+N)+2
    Soft and hard bonding2+(N+X+N)+22+(N+X+N)+22+(N+X+N)+2
    PTH filling processPTH resin plug hole + plating fill
    Electroplated hole/copper plug hole
    PTH resin plug hole + plating fill
    Electroplated hole/copper plug hole
    PTH resin plug hole + plating fill
    Electroplated hole/copper plug hole

    Technical ltemMassProductAdvanced Technology
    201620172018
    Max.Layer Count26L36L80L
    Through-hole plate2~45L2~60L2~80L
    Max.PCBSize(in)24*52"25*62"25*78.75"
    The layer number of FPC1~36L1~50L1~60L
    Max.PCBSize(in)9.8"*196"9.8"*196"10"*196"Reel to reel
    Layeredplatelayer2~12L2~18L2~26L
    Max.PCBSize(in)9"*48"9"*52"9"*62"
    Combination of hard and soft layers3~26L3~30L3~50L
    Interconnect HDI5+X+5Interconnect HDI7+X+7Interconnect HDI8+X+8,Interconnect HDI
    HDI PCB4~45L4~60L4~80L
    Interconnect HDI3+20+34+X+4Interconnect HDI4+X+4,Interconnect HDI
    Max.PCBSize(in)24"*43"24"*49"25"*52"
    MaterialFR-4 RogersFR-4 RogersFR-4 Rogers
    Base materialHalogenfree,LowDKHalogenfree,LowDKHalogenfree,LowDK
    Build-up MaterialFR-4FR-4FR-4
    BOard,Thickness(mm)Min.12L(mm)0.430.42~8.0mm0.38~10.0mm
    Min.16L(mm)0.531.60~8.0mm0.45~10.0mm
    Min.18L(mm)0.632.0~8.00.51~10.0mm
    Min.52L(mm)0.82.50~8.0mm0.65~10.0mm
    MAX(mm)3.510.0mm10.0mm
    Min.CoreThickness um(mil)254"(10.0)254"(10.0)0.10~254(10.0mm)
    Min.Build up Dielectric38(1.5)32(1.3)25(1.0)
    BaseCopperWeightInner Layer4/1-8 OZ4/1-15 OZ4/1-0.30mm
    Out Layer4/1-10 OZ4/1-15 OZ4/1-30 OZ
    Gold thick1~40u"1~60u"1~120u"
    Nithick76~127u"76~200u"1~250u"
    Min.HOle/Land um(mil)150/300(6/12)100/200(4/8)100/200(4/8)
    Min.Laser via/landum(mil)60/170(2.4/6.8)50/150(2/6)50/150(2/6)
    Min. IVH,Hole size/landum(mil)150/300(6/12)100/200(4/8)100/200(4/8)
    DieletricThickness38(1.5)32(1.3)32(1.3)
    125(5)125(5)125(5)
    SKipviaYesYesYes
    viaoNhie(laserviaon BuriedPTH)YesYesYes
    Laser Hole FillingYesYesYes
    TechnicalltemMass ProductAdvanced Technolgy
    2017year2018year2019year
    Drill hole depth ratioThroughHole2017year.40:1.40:1
    Aspet RatioMicro Via.35:11.2:11.2:1
    Copper Filling Dimple Size um(Mil)10(0.4)10(0.4)10(0.4)
    Min.LineWidth&spacelnner Layer um(mil)45/45(1.8/1.8)38/38(1.5/1.5)38/38(1.5/1.5)
    Plated Layer um(mil)45/45(1.8/1.8)38/38(1.5/1.5)38/38(1.5/1.5)
    BGAPitch mm(Mil)0.30.30.3
    Min.PTH Hole ring um(mil)75(3mil)62.5(2.5mil)62.5(2.5mil)
    Line Width Control∠2.5MIL±0.50±0.50±0.50
    2.5Mil≤L/W∠4mil±0.50±0.50±0.50
    ≦3mil±0.60±0.60±0.60
    Laminated structureLayer by layer3+N+34+N+45+N+5
    Sequential Build-up20L Any Layer36L Any Layer52L Any Layer
    Multi-layer overlayN+NN+NN+N
    N+X+NN+X+NN+X+N
    sequential Lamination2+(N+X+N)+22+(N+X+N)+22+(N+X+N)+2
    Soft and hard bonding2+(N+X+N)+22+(N+X+N)+22+(N+X+N)+2
    PTH filling processPTH resin plug hole + plating fill
    Electroplated hole/copper plug hole
    PTH resin plug hole + plating fill
    Electroplated hole/copper plug hole
    PTH resin plug hole + plating fill
    Electroplated hole/copper plug hole
